配件系列 — FA/FB法蘭
技術(shù)參數(shù)
外型尺寸
| 缸徑/符號 | 32 | 40 | 50 | 63 | 80 | 100 | 125 | 160 | 200 | 250 |
| BA | 29 | 33 | 40 | 40 | 51 | 51 | 63.5 | 72 | 80 | 103 |
| BB | 10 | 10 | 10 | 12 | 15 | 15 | 18 | 21 | 22 | 25 |
| BC | 47 | 54 | 65 | 76 | 93 | 110 | 138 | 178 | 220 | 280 |
| BD | 33 | 36 | 47 | 56 | 70 | 84 | 90 | 115 | 135 | 165 |
| BE | 72 | 85 | 103 | 118 | 142 | 160 | 210 | 266 | 320 | 385 |
| BF | 58 | 70 | 86 | 98 | 119 | 138 | 180 | 230 | 270 | 330 |
| BH | 6.8 | 6.8 | 6.8 | 8.2 | 11 | 11 | 13 | 13 | 17 | — |
| AJ | 11 | 11 | 11 | 14 | — | 17 | 19.5 | 19.5 | 25 | — |
| AK | 7 | 7 | 7 | 9 | 11 | 11.5 | 13.8 | 13.8 | 17.8 | M20 |
| BP | 7 | 7.8 | 96 | 9 | 11.5 | 11.5 | 17.8 | 17.8 | 23 | 25 |
| T | 33 | 37 | 47 | 56 | 70 | 84 | 110 | 140 | 175 | 220 |
